CORE TECHNOLOGY
Bipolar Series
Bipolar series provides scalable multi-channel Source Measure Units (SMUs) with configurable bipolar outputs for precision measurement and automated test systems.
Multi-Channel Architecture
Available in 8, 40, 80, and 120 independent SMU channels, providing scalable configurations for laboratory and automated test systems.
Bipolar Output Performance
Supports up to ±16 V bipolar output, 16-bit resolution, and ±500 mA output current.
Equipped with Gigabit Ethernet and USB interfaces for seamless integration into automated measurement and control systems.
Flexible Connectivity
The Bipolar Series provides scalable multi-channel Source Measure Units (SMUs) with configurable bipolar outputs for precision measurement and automated test systems.
Bipolar Series
CORE TECHNOLOGY
Multi-Channel Architecture
The XDAC-MUB series provides scalable multi-channel Source Measure Units (SMUs) with configurable bipolar outputs for precision measurement and automated test systems.
Bipolar Output Performance
Supports up to ±16 V bipolar output, 16-bit resolution, and ±500 mA output current.
Flexible Connectivity
Equipped with Gigabit Ethernet and USB interfaces for seamless integration into automated measurement and control systems.
Empowering Future Systems
Bipolar technology forms the critical analog backbone for applications requiring immense data throughput and uncrompomised signal integrity.
Optical Communication
Supporting precise control and characterization of photonic components across up to 120 channels.
AI Infrastructure
Enabling scalable electrical testing of low-power components within AI and advanced computing systems.
Data Centers
Providing programmable voltage and current sourcing for precision testing of low-power components in data centers.
RF & Microwave
Supporting programmable DC sourcing and measurement for low-power components within RF and microwave systems.
Test & Measurement
Precision instrumentation requiring ultra-low noise floors and exact timing control for component characterization.
Industrial Electronics
Robust driver circuits capable of operating reliably in high-temperature and electrically noisy environments.
Feature Products
XDAC-8MUB-R4G8
An 8-channel SMU with 16-bit resolution, bipolar outputs, and USB/Ethernet connectivity.
-
8 SMU Channels
-
± 16 V Bipolar
-
± 500 mA Output
Feature Products
XDAC-40MUB-R4G8
A 40-channel SMU with 16-bit resolution, bipolar outputs, and USB/Ethernet connectivity.
-
40 SMU Channels
-
± 16 V Bipolar
-
± 500 mA Output
Feature Products
XDAC-80MUB-R4G8
A 80-channel SMU with 16-bit resolution, bipolar outputs, and USB/Ethernet connectivity.
-
80 SMU Channels
-
± 16 V Bipolar
-
± 500 mA Output
Feature Products
XDAC-120MUB-R4G8
A 120-channel SMU with 16-bit resolution, bipolar outputs, and USB/Ethernet connectivity.
-
120 SMU Channels
-
± 16 V Bipolar
-
± 500 mA Output
Integrated Solutions
Technical Resources
Design Guideline
PCB and analog design guide
Application Note
Best practices for impedance matching and layout
Frequently Asked Question
Answers regarding yield, integration, and supply
